SSEWDM08374D-B, 0.5 Hp (0.37 kW), 1800 RPM @ 60 Hz / 1500 RPM @ 50 Hz, 460 V, 3 Ph, TENV (Totally Enclosed Non-Ventilated), Frame 80, B5

This general-purpose washdown-duty IEC motor is designed for food-safe and high-pressure washdown environments, offering dual-frequency operation in a stainless steel frame with totally enclosed non-ventilated construction.

KEY FEATURES

• Model: SSEWDM08374D-B

• Horsepower: 0.5 Hp (0.37 kW)

• Voltage: 460 V – 3 Phase

• Speed: 1800 RPM @ 60 Hz / 1500 RPM @ 50 Hz

• Frame: 80

• Enclosure: Totally Enclosed Non‑Ventilated (TENV)

• Poles: 4

• IP Code: IP69

• Ambient Rating: 40 °C

• Insulation Class: F

• Weight: 67.999 lb

• Origin: FI

• Auxiliary Box: N‑END TOP

• Starting Method: Full Voltage

• Duty Rating: S1 (Continuous)

• Speed Code: Single Speed

• Specification Number: SSEWDM08374D-B

• Commodity Code: 8501514040

• Stock Status: Deleted
