LENZE  |  SKU : EMN-018490

ESV552N02TMD, SMV SERIES SENSORLESS Vector 7.5Hp / 240V, 3PH(i/p) / 23.0A(o/p) Cont. / NEMA4X c/w DISCONNECT (Frame AB1)

$2,184.88
shipping

Estimation des frais de livraison

Description

ESV552N02TMD, SMV SERIES SENSORLESS Vector 7.5Hp / 240V, 3PH(i/p) / 23.0A(o/p) Cont. / NEMA4X c/w DISCONNECT (Frame AB1)

Category Features
Performance - Dynamic Torque Response
- 2 Independent Accel/Decel Ramps (Linear, S-Type, Ramp-to-Stop)
- Fixed Accel Boost
- Output Frequency: 500 Hz (1,000 Hz optional)
Switching Frequency Configurable: 4, 6, 8, 10, 12, or 16 kHz
Logic Control Universal Logic Assertion: Positive/Negative Logic Input
Braking Functions - DC Injection Braking
- Optional Regenerative Braking
- Over Temperature Protection
Speed Commands - Keypad
- Potentiometer
- Jog
- Floating Point Control
- 8 Preset Speeds
- Scalable Voltage: 0-10 VDC
- Scalable Current: 4-20 mA
Process Control PID Modes: Direct/Reverse Acting, Sleep Mode
Voltage Monitoring - High/Low DC Bus Voltage Protection
- Low Line Voltage Compensation
Current Monitoring - Motor Overload Protection
- Current Limiting Safeguard
- Phase Loss Protection
- Ground Fault and Short Circuit Protection
Loss of Follower - Protective Fault
- Preset Speed/Setpoint Transition
- System Notification
Safety Lockable Disconnect (Closed Position)
