DL1076, 3/4Hp, 1075 RPM, 115 V, 1 Ph, 60 Hz, Open Air‑Over, Frame 48

This single‑phase fan and blower motor delivers 0.75 Hp at 1075 RPM with three selectable speeds in a compact NEMA 48 frame. It features an open air‑over enclosure and is designed for resilient‑ring mounting in HVAC blower applications.

KEY FEATURES

• Model: DL1076

• Product Type: Fan and Blower Motor

• Horsepower: 3/4 Hp (0.56 kW)

• Voltage: 115 V @ 60 Hz – 1 Phase

• Speed: 1075 RPM @ 60 Hz

• Frame: 48

• Enclosure: Open Air‑Over (OAO)

• Service Factor: 1

• Efficiency: approximately 65 %

• Current: approximately 8.9 A to 9.5 A (full load)

• Duty: Continuous / Air Over

• Insulation Class: B

• Mounting: Resilient Ring

• Shaft: 1/2″ diameter × ~4 in length

• Bearings: Sleeve bearings

• Frame Material: Rolled Steel

• Rotation: Reversible (CW/CCW)

• Number of Speeds: 3

• Certifications: UL Recognized, CSA Certified

• Ambient Rating: 40 °C

• Special Feature: Automatic overload protection

This motor offers versatile mounting and reversible rotation, making it well suited for HVAC blower systems requiring reliable multi‑speed control.
