E-Motor Nations  |  SKU : EMN-018181

3742H, Us Motors, 3/4Hp,1075 Rpm, 460V,1Ph,Fr:48,Tenv, 5KCP39SGU542BS,

$419.80
shipping

Estimation des frais de livraison

Description

3742H, Us Motors,5KCP39SGU542BS,K055WGE0946014B,Carrier 205051002,OAN747.

ADD Rain Shiel 1330A (1/2'' Bore)

Model_Number K055WGE0946014B
PRODUCT NAME .75 HP - TEAO - 1075
PHASETYPE 1_PERMANENT SPLIT CA  10 Uf 370 Vac
MOTOR ENCLOSURE TEAO
HORSEPOWER .75
KILOWATTS 0.6
POLES 6
NUMBER SPEEDS 1
RPM 1075
HERTZ 60
VOLTS PRIMARY 460 V
VOLTS 460
FRME 48
SHAFT CODE Y
STATOR DIAMETER 5.5
STACK 3
MOUNTING STUD
MOTOR TYPE FHP
OPPOSITE END BEARING 6203
SHAFT END BEARING 6203
AMBIENT 70
ROTATION CW LEAD END REV
SERVICE FACTOR 1
RUNCAPMFD 10
RUNCAPVOLTS 370
SHIPPING WEIGHT 18
THERMAL PROTECTION AUTOMATIC RESET
BREAKDOWN TORQUE 78.69
BREAKDOWN TORQUE UOM OZFT
LOCKED ROTOR TORQUE 16.97
LOCKED ROTOR TORQUE UOM OZFT
INSULATION CLASS F
KVA CODE LETTER A
LOCKED ROTOR AMPS 4.52
FULL LOAD AMPS PRIMARY 2.0
