Xactone  |  SKU: EMN-018826

XRA1036, Xactone, Fan Coil & Air Conditioner Motor, 1/3 HP, 1 Ph, 60 Hz, 208-230 V, 1075 RPM, 3 Speed, 48 Frame, SEMI ENCLOSED

$268.01
shipping

Estimate shipping

Description

XRA1036, Xactone,Replaces Genteq 3682, Century RA1036, US Motor NA1036, Rotom R52102,

Category Details
Application Fan Coil, Room Air Conditioner, Blower Motor
Diameter 5.6"
Frame Size 48
Electrical Type Permanent Split Capacitor (PSC)
Capacitor Required 5 Mfd - 370V (Not Supplied)
Thermal Protection Yes
Insulation Class Class B
Ambient Temperature 60°C
Motor Orientation Horizontal
Mounting Resilient Ring / Extended Studs
Bearings Ball Bearings (Drive End & Opposite Drive End)
Shaft Type Flat
Shaft Diameter 0.500"
Shaft Extension 8.2" x 0.5" x 7.2"
Double Shaft Yes (1/2" Diameter)
Leads 35"
Enclosure Type Semi-Enclosed, Air Over
Frame Material Rolled Steel
Speed (RPM) 1075
Voltage 208-230V
Poles 6
Rotation Counterclockwise (Lead End)
Starting Method Across The Line
Overall Length 19.99"
Frame Length 4.00"
Design Upgrade Converted from Sleeve Bearing to Ball Bearing
