E-Motor Nations  |  SKU: EMN-019357

9338, (KBPC-240D) SCR DC Drive 1Hp-2Hp 10.2A 115/230VAC Input 90/180VDC NEMA 4X Enclosure - Black

$477.72
shipping

Estimate shipping

Description

9338, (KBPC-240D) SCR DC Drive 1Hp-2Hp 10.2A 115/230VAC Input 90/180VDC NEMA 4X Enclosure - Black

Category Specifications
Model KBPC-240D
Drive Type SCR DC Drive
Horsepower Range 1 HP - 2 HP
Current Rating 10.2A
Input Voltage 115/230 VAC
Output Voltage 90/180 VDC
Enclosure Rating NEMA-4X / IP-65 (Watertight & High Humidity Protection)
Selectable Features - Motor voltage: 90/180 VDC
- Motor current range: 0.25 to 10A
- Input signal: 0-5VDC / 0-20VDC
- Armature/tachometer feedback
- Tachometer voltages: 7, 25, 50 V/1000 rpm
Standard Features - Armature fusing
- Electronic start/stop
- LED indicators (Power On, Stop, Overload)
Protection Features - Short Circuit & Timed Current Limit (TCL) to prevent motor burnout and demagnetization of PM motors
Analog Adjustments - Min, Max, Accel, Decel, IR, CL, TCL, Jog
Approvals UL, CSA, CE
Included Components - Line fuse
- Resistor and armature fuse
Color Black
Dimensions 5.90" (W) x 9.50" (H) x 5.00" (D)
