20503, 1/30 Hp, 1500/3175 RPM, 115 V, 1 Ph, 60 Hz, Open (C‑Frame)

This compact single‑phase inducer blower motor is designed for residential HVAC applications, offering two‑speed operation and direct replacement compatibility with multiple OEM part numbers.

KEY FEATURES

• Model: 20503

• Product Type: Inducer motor

• Voltage: 115 V @ 60 Hz

• Speed: 3175 RPM (High) / 1500 RPM (Low)

• Current: 1.19 A (High) / 0.4 A (Low)

• Horsepower: 1/30 Hp (≈ 0.033 Hp)

• Enclosure: Open (C‑Frame style)

• Insulation Class: B

• Rotation: CW Shaft End

• Ambient Rating: 40 °C

• Bearings: Ball Bearing

• Thermal Protection: Automatic Overload Protection

The two‑speed design and broad OEM compatibility make this motor a versatile replacement for furnace inducer applications, while its compact open‑frame construction supports ease of installation and reliable performance.

CROSS REFERENCE

• 326628-703 / 326628-713 / 326628-763

• 347822-763 / 347822763

• 349336-763

• HC21ZE127

• 66763
