T13C2JC, General Purpose, 1/3Hp, 1725 RPM, 115/208-230V, 1PH, 60Hz, TEFC, Fr. 56C, C055KKT4986015B
T13C2JC, General Purpose, 1/3Hp, 1725 RPM, 115/208-230V, 1PH, 60Hz, TEFC, Fr. 56C, C055KKT4986015B est en rupture de stock et sera expédié dès qu’il sera de retour en stock.
Impossible de charger la disponibilité pour le Service de retrait
Estimation des frais de livraison
Veuillez corriger les erreurs suivantes :
T13C2JC, General Purpose, 1/3Hp, 1725 RPM, 115/208-230V, 1PH, 60Hz,...
Description
Description
T13C2JC, General Purpose, 1/3Hp, 1725 RPM, 115/208-230V, 1PH, 60Hz, TEFC, Fr. 56C, C055KKT4986015B
KEY FEATURES
• Model Number: C063HDJ1384015B
• Output: 1/3 HP (0.3 kW)
• RPM: 1725
• Voltage: 115/230 V
• Phase: 1 – Capacitor Start
• Poles: 4
• Frequency: 60 Hz
• Frame: 56
• Mounting: C-Face
• Enclosure: TEFC
• Service Factor: 1.15
• Ambient Temperature: 40°C
• Insulation Class: B
• Efficiency: 59.5 %
• Rotation: Reversible
• Start Capacitor: 198.45 µF
• Locked Rotor Torque: 73.41 oz.ft
• Breakdown Torque: 54.95 oz.ft
• Full Load Amps: 6.6 / 3.3 A
• Thermal Protection: Manual Reset
