CENTURY | SKU : EMN-016158

OAN747, CENTURY, 3/4 HP, 1075 RPM, 460V, F48U09A27, K055NPB1104031B, CONDENSER FAN

Name: OAN747, CENTURY, 3/4 HP, 1075 RPM, 460V, F48U09A27, K055NPB1104031B, CONDENSER FAN
Brand: CENTURY
SKU: EMN-016158
Price: 895.94 CAD
Availability: InStock

$895.94

Frais de livraison calculés lors du paiement.

shipping

Estimation des frais de livraison

Pays

Code postal

Description

OAN747, CENTURY,OAN747, 8233, K055NPB1104031B, F48U09A27, 5481H, F48M31A50, 02424110016, 5KCP39SGL274AS, F48A06C71, F48M13A50, F48Z18A01, K55HXWGE0946, 5KCP39NGN863,

Replaced by 3742H,

General Specifications

Model :		Catalog No :	OAN747
Part Description :	MODEL-RFHP-48FR	Category :	OEM Replacement
Stock :	Yes

Nameplate Specifications

Output HP :	3/4 HP	Output KW :	0.56 kW
Frequency :	60 Hz	Voltage :	460 V
Current :	2.0 A	Speed :	1075 RPM
Service Factor :	1	Phase :	1
Duty :	Air Over	Insulation Class :	B
Frame :	48Y	Enclosure :	Semi Enclosed
Overload Protector :	Automatic	Ambient Temperature :	60 °C
UL :	Recognized	CSA :	Y
CE :	N

Technical Specifications

Electrical Type :	Permanent Split Capacitor	Starting Method :	Induction Run
Poles :	6	Rotation :	Counterclockwise Lead End
Mounting :	Round Belly Band	Motor Orientation :	Vertical Shaft Up
Drive End Bearing :	Ball	Opp Drive End Bearing :	Ball
Frame Material :	Rolled Steel	Shaft Type :	Double Flat
Overall Length :	10.36 in	Frame Length :	6.50 in
Shaft Diameter :	0.500 in	Shaft Extension :	1 7/8 in
UPC :	786674026965	Weight :	27.00 LB

Features

OEM Direct Replacement Motor
5.6" Diameter - 48 Frame
Permanent Split Capacitor
Thermally Protected
Open Shaft End and Opposite Shaft End End-Frame, Enclosed Shell, Air Over
Class B Insulation, 60°C Ambient
Ball Bearing
1/2" Diameter Shaft with Double Flat
96" Leads with Quick Connect Terminals
Belly Band Mount Vertical Shaft Up
