Y560, 7.5Hp, 1800 RPM, 575 V, 3 Ph, 60 Hz, TENV, Frame 213TC, 213THTL7736

This general-purpose three-phase AC motor is designed for inverter-duty industrial applications, offering a totally enclosed non‑ventilated enclosure in a 213TC frame optimized for vector drive use.

KEY FEATURES

• Model: Y560

• Product Type: Electric Motors

• Horsepower: 7.5 Hp (5.6 kW)

• Voltage: 575 V @ 60 Hz – 3 Phase

• Speed: 1800 RPM @ 60 Hz

• Frame: 213TC

• Enclosure: Totally Enclosed Non‑Ventilated (TENV)

• Service Factor: 1.0

• Efficiency: 90.2 %

• Current: 8.4 A

• Duty: Continuous

• Insulation Class: F

• Design Code: B

• KVA Code: H

• Rotation: Reversible

• Number of Speeds: 1

• IP Code: 43

• Ambient Rating: 40 °C

• Bearings: Drive End: 6309; Opposite Drive End: 6307

• Frame Material: Aluminum

• Mounting: Rigid Base, F1/F2 Capable

• Certifications: UL Recognized, CSA, CE

The motor’s inverter‑duty rating and TENV design make it well‑suited for harsh industrial environments requiring precise speed control and protection from dust and debris.
