12419, 1/12-1/15-1/20Hp, 1550/1400 RPM, 115/230 V, 1 Phase, Shaded‑Pole Fan Motor

This compact shaded‑pole fan motor is designed for refrigeration and HVAC applications, offering dual‑voltage and dual‑speed operation for flexible installation and efficient air movement in condenser or evaporator assemblies.

KEY FEATURES

• Model: 12419

• Product Type: Electric Motors

• Horsepower: 1/12 Hp (approx. 0.083 kW) – also available in 1/15 Hp and 1/20 Hp variants

• Voltage: 115 V / 208‑230 V – 1 Phase

• Speed: 1550 RPM @ 115 V / 1400 RPM @ 230 V

• Amperage: 1.0 A @ 115 V / 0.5 A @ 230 V

• Enclosure: Shaded‑pole (open)

• Mounting: All positions

• Rotation: Reversible

• Bearings: Ball

• Frame: Standard 48‑frame (~5.6" diameter body)

• Insulation Class: B

• Ambient Rating: 40 °C

• Protection: Thermally protected

• Capacitor: Included (4 µF/370 V)

This motor’s dual‑voltage and dual‑speed capability makes it ideal for a variety of refrigeration and HVAC fan replacement scenarios, while its shaded‑pole design ensures simple, reliable operation in tight spaces.

CROSS REFERENCE

• 9721 / SS9721

• D1127 / D1125

• JF2F008 / JF2F008N

• 2NFD1

• 2412929

• US-R90721
