HG705A, 0.33/0.07 Hp, 1800 RPM, 115 V, 1 Ph, 60 Hz, Drip‑Proof (DP), Frame 56Z, 056S84DRS40001A1

This single‑phase fan and blower motor is designed for HVAC/R applications, offering dual‑speed operation in a compact 56Z frame with drip‑proof enclosure and automatic thermal protection.

KEY FEATURES

• Model: HG705A

• Product Type: Fan and Blower Motor

• Horsepower: 0.33 Hp (0.25 kW) and 0.07 Hp (0.05 kW)

• Voltage: 115 V @ 60 Hz – 1 Phase

• Speed: 1800 RPM @ 60 Hz

• Frame: 56Z

• Enclosure: Drip‑Proof (DP)

• Duty: Continuous

• Thermal Protection: Automatic

• Number of Speeds: 2

• Certifications: UL Recognized

• Ambient Rating: 40 °C

Closing Remarks

This compact dual‑speed blower motor is well‑suited for HVAC/R systems requiring reliable continuous operation in moderate ambient temperatures, with built‑in thermal protection and recognized safety certification.
