ELP32P1D, 1.5Hp, 3540RPM, 208-230/460V, 3Ph, 60-50Hz, TEFC, Frame 143T, IP55, eLline Premium Cast Iron

ELP32P1D, 1.5Hp, 3540RPM, 208-230/460V, 3Ph, 60-50Hz, TEFC, Frame 143T, IP55, eLline Premium Cast Iron

KEY FEATURES

• Catalog Number: ELP32P1D

• Output Power: 1.5 HP (1.10 kW)

• Voltage: 208–230 / 460 V

• Frequency: 60 Hz

• Speed: 3540 RPM

• Synchronous Speed: 3600 RPM

• Frame: 143T / TC

• Full Load Amps: 4.3 A @ 208–230 V / 2.1 A @ 460 V

• Locked Rotor Amps: 36.2 A @ 208 V / 40.0 A @ 230 V / 20.0 A @ 460 V

• Service Factor: 1.40

• Torque: 2.3 lb·ft

• Efficiency (Full Load): 84.0%

• Guaranteed Efficiency: 82.0%

• Power Factor (Full Load): 78.0

• NEMA Design: B

• NEMA Code Letter: M

• Bearings: 6205 2Z (DE & ODE)

• Noise Level: 80 dBA
