A1200, 1/2Hp, 1550/1450 RPM, 115/230 V, 1 Ph, 60 Hz, Open (Air Over), Frame 48, 7024-1301

This centrifugal blower with a permanent split capacitor motor is designed for HVAC and ventilation applications, offering two-speed operation and dual-voltage flexibility in a compact open-air-over configuration.

KEY FEATURES

• Model: A1200

• Product Type: Permanent Split Capacitor Centrifugal Blower

• Horsepower: 1/2 Hp

• Voltage: 115/230 V @ 60 Hz

• Speed: 1550 RPM / 1450 RPM @ 60 Hz

• Phase: 1 Phase

• Enclosure: Open (Air Over)

• Number of Speeds: 2

• Current: 8.0 A / 4.0 A

• Insulation Class: B

• Thermal Protection: Thermally Protected

• Ambient Rating: 40 °C

• Bearing Type: Sleeve Bearings

• Blower Outlet Shape: Rectangle

• Blower Outlet Flange: No
