E-Motor Nations  |  SKU: EMN-018799

B-VFD550B43C, (B Series) 75Hp 55kW (CT 110A) / 100Hp 75kW (VT 138A), 3 Ø 460VAC, 0-2000.00Hz (o/p), (V/Hz, SVC, VC+PG), NEMA 1, Frame E

$6,338.92
shipping

Estimate shipping

Description

B-VFD550B43C, (B Series) 75Hp 55kW (CT 110A) / 100Hp 75kW (VT 138A), 3 Ø 460VAC, 0-2000.00Hz (o/p), (V/Hz, SVC, VC+PG), NEMA 1, Frame E

Equivalent : Delta C-VFD550C43A & CP-VFD550CP43S-21

Category Details
Control Methods - Volt/Hertz
- Sensorless Vector
- Closed Loop Vector Control
Torque Rating Constant Torque rated
Programmable Speed 0 ~ 2000 Hz for high-speed applications
Output Current Adjustable up to 120% of the drive's nominal capacity
Input Voltage - ‘’240/1/60’’ models accept both single-phase and three-phase input
Inputs - 11 Digital Inputs (4 dedicated, 7 programmable)
- 3 Analog Inputs
Outputs - 4 Digital Outputs
- 1 Analog Output
- 1 Digital Frequency Output
Communication - RS-485 communication port
- Standard protocols: Modbus RTU & ASCII575
Dynamic Braking Built-in dynamic braking transistors for drives up to 15HP
Applications Suitable for precise motor control in high-speed and constant torque applications
