E-Motor Nations | SKU:
EMN-018323
BSM100C-4150BA,Resolver,S4P160W110,Baldor,Brake,AC Brushless Servo,C-Series,
Regular price
$6,871.91
Unit price
/
Unavailable
BSM100C-4150BA,Resolver,S4P160W110,Baldor,Brake,AC Brushless Servo,C-Series, is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
shipping
Estimate shipping
Please correct the following errors:
BSM100C-4150BA,Resolver,S4P160W110,Baldor,Brake,AC Brushless Servo,...
Regular price
$6,871.91
Unit price
/
Unavailable
Description
Description
BSM100C-4150BA, Baldor, ABB, Spec S4P160W110, Brake Resolver T'STAT,
Note: Built-to-order (Delivery to be confirmed by ABB Baldor 12-14 week)
| CAT.NO. | BSM100C-4150BA | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SPEC. | S4P160W110 | ||||||||||||||||
| MFG.NO. | Brake Motor | ||||||||||||||||
| TORQ CONT STALL | 20 NM | ||||||||||||||||
| CUR CONT STALL/A RMS | 16.9 | ||||||||||||||||
| POWER | 5.03KW | ||||||||||||||||
| RATED SPEED/RPM(1/MIN) | 2400 | ||||||||||||||||
| RATED BUS VOLTS | 320 | ||||||||||||||||
| PEAK CUR/A RMS | 50.8 | ||||||||||||||||
| MAX SPEED/RPM(1/MIN) | 6000 | ||||||||||||||||
| IP | 54 | IC | 410 | WT. | 29.5 | ||||||||||||
| CLASS | F | 25C RATED | |||||||||||||||
| Caractéristique | Détail |
|---|
| Enclosure | TENV |
| Motor Type | S448B |
| Nameplate Speed | 2400 |
| Agency Approvals | CE, CSA, TUV, UR, WEEE |
| Base Indicator | Bracket Mounted |
| Dimensional Drawing Numbers | S4LYP124 |
| Frame | D165D |
| Frame Material | Exposed Laminations |
| Motor Lead Quantity/Wire Size | 3 @ 14 AWG |
| Motor Standards | IEC |
| Mounting Arrangement | F1 |
| Nameplate Output | 4.48KW |
| Shaft Rotation | Reversible |
