OMNIDRIVE | SKU:
EMN-015578
FD161C, eMotorteK, 1/3 HP, 1750 RPM, 115/208-230V, FRAME: 56C, TEFC
Regular price
$324.75
Unit price
/
Unavailable
FD161C, eMotorteK, 1/3 HP, 1750 RPM, 115/208-230V, FRAME: 56C, TEFC is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
shipping
Estimate shipping
Please correct the following errors:
![FD161C, 1/3 HP, 1800 RPM, 115/208-230V,FRAME 56C, TEFC,OMNIDRIVE - SINGLE PHASE MOTORS - OMNIDRIVE - electric motors - [product_tags]- motor electric - moteur électrique - moteurs - drive - replacement - venmar - hvac - méchoui - capacitor - condensateur](http://www.emotornations.com/cdn/shop/products/FD161C.jpg?v=1756480350&width=112)
FD161C, eMotorteK, 1/3 HP, 1750 RPM, 115/208-230V, FRAME: 56C, TEFC
Regular price
$324.75
Unit price
/
Unavailable
Description
Description
FD 161C, OMNIDRIVE MOTOR
REPLACE F101 MARATHON, MTR-134FDC MAXMOTION, FD13CM2P US MOTORS, C225 CENTURY, FDL3501M BALDOR, 113256.00 LEESON
| HP | 1/3 |
| VOLTAGE | 115-208/230 |
| AMPS | 4.30/2.30 |
| RPM | 1725 |
| FREQUENCY | 60 HZ |
| LENGTH | 12.21” |
| ENCLOSURE | TEFC |
| SHAFT DIAMETER | 5/8'' |
| TYPE | FARM DUTY CAPCACITOR START |
| SPEED | 1 |
| DIAMETER | 6,5'' |
| FRAME | 56C |
| BEARING SLEEVE | BEARING |
| ROTATION | REVERSIBLE |
| PROTECTOR | THERMALLY PROTECTED |
| PHASE | 1 |
| AMBIENT TEMP | 40 C |
|
S.F |
1.15 |
| FEATURE(S) | Rolled Steel Construction, Class ‘B’ Insulation, Continuous Duty, UL Listed & CSA Approved, Removable Rigid Base, FD161C |
