E-Motor Nations  |  SKU: EMN-019072

CP003502NPW01, Rolled Steel NEMA Premium Efficiency 3Hp 3480 Rpm 2P 143/5TC 3Ph 575 V 60 Hz IC01 - ODP - Foot-mounted

$580.20
shipping

Estimate shipping

Description

CP003502NPW01,  Rolled Steel NEMA Premium Efficiency 3Hp 3480 Rpm 2P 143/5TC 3Ph 575 V 60 Hz IC01 - ODP - Foot-mounted

Category Specification/Feature
Power 3 HP (2.2 kW)
Voltage 575 V, 60 Hz
Poles 2
Speed 3600 rpm
Torque 4.53 ft.lb (Rated), 229% (Locked Rotor), 300% (Breakdown)
Current 2.87 A (Rated), 23.0 A (Locked Rotor)
Mounting Foot-mounted (F-1)
Frame 143/5TC, Rolled Steel
Enclosure Without Fan Cover, Without Fan
Insulation Class F, 80 K Temp Rise
Bearings 6205 ZZ (DE), 6203 ZZ (NDE)
Rotation CW and CCW
Overload Without overload protector
Grease Mobil Polyrex EM
Noise Level 62.0 dB(A)
Service Factor 1.15
Sealing Without Bearing Seal
Flange C
