8615, (KBWT-26) PWM DC Drive 1.5Hp 6A 230VAC 1PH Input 260VDC Output Non-Reversing Chassis

Specification	Details
Model Number	KBWT-26
Input Voltage	208/230 VAC
Motor Type Supported	PWM and SCR rated Permanent Magnet (PM) DC Motors
Horsepower Range	1/50 to 1.5 HP
PWM Advantages	- Nearly pure DC current (Form Factor 1.05)
	- Excellent dynamic load response
	- Lower motor noise and longer brush life
	- Reduced motor heating allows smaller motors
	- Higher output voltage = increased speed
	- Pulse-by-pulse current sensing for short circuit protection
Active Bridge Feature	Substantial reduction in AC line surge current at startup
Short Circuit Protection	Built-in safety circuit shuts down on main transistor failure to prevent high-speed runaway
Thermal Management	Heat-spreader construction prevents overtemperature cycling
Motor Burnout Protection	I x t shutdown if motor is overloaded for a set time
Potentiometer Safety Circuit™	(Optional) Prevents startup unless speed pot is set to zero
Diagnostic LEDs	Power On and Overload (OL) indicators
Terminal Type	Quick disconnect terminals (standard)
Startup Safety	Auto inhibit provides smooth/safe startup on rapid AC switching
Control Input Options	5K potentiometer, isolated 0–5 VDC analog signal, or PWM microprocessor output
Dimensions (H x W x D)	5.00" x 7.00" x 2.00"
Line Fuse	Required
Resistor & Armature Fuse	Required

The KBWT series Pulse-Width Modulated (PWM) DC Drives are rated for 1/2 to 2.2 horsepower motors. This chassis drive series
consists of five models that are designed for high current applications. Several models are offered, which provide the user a
choice of input voltage and output current. An important feature of these chassis drives is its active bridge circuitry, which limits
inrush current during AC line startup and prevents control runaway due to a shorted output transistor. The KBWT also contains
Timed Current Limit (TCL) which provides motor burnout protection. The drive also contains a Potentiometer Safety Circuit (PSC),
which prevents motor rotation unless the signal input is first set to zero when power is applied. Features include an Armature
fuse holder.* This drive also contains Auto Inhibit® which provides a smooth, safe start during rapid switching of the AC line. An
optional Potentiometer Safety Circuit requires the pot to be at zero for start up
